Performance Tuning

About Me

• Matt Godbolt
• Low-latency C++ developer at HRT
• Creator of Compiler Explorer

Placing Orders

• Many exchanges use FIX protocol
• ASCII KEY=VALUE pairs
• Separated by SOH byte ('␁' / '\x01')
• Not very efficient
• Requires several binary-to-decimal conversions

Simplified Order

NEW stock price quantity

/// hide
#include <sstream>
#include <string>
/// unhide
std::string newOrder(std::string stock, int price, int quantity) {
  std::stringstream s;
  s << "NEW " << stock << " " << price << " " << quantity;
  return s.str();
}

How Fast Is It?

• Time 10 million orders, get average time
• ~1040ns per order (Intel i7-10510U @ 1.8GHz, GCC 11 static)
• We can do better!

Profile

$ perf record ./app
$ perf report

20.64%  __dynamic_cast
 6.17%  __cxxabiv1::__si_class_type_info::__do_dyncast
 5.78%  __ostream_insert
 4.96%  __cxxabiv1::__vmi_class_type_info::__do_dyncast
 4.33%  __strcmp_avx2
 3.69%  ostream::_M_insert<long>
 3.51%  basic_streambuf::xsputn
 3.10%  newOrder
 2.87%  std::locale::id::_M_id
 2.84%  num_put::_M_insert_int

Dynamic cast?

__dynamic_cast()
bool std::has_facet(std::locale const&)
std::basic_ios::_M_cache_locale(std::locale const&)
std::basic_ios::init(...)
std::basic_istream::basic_istream(...)
std::basic_iostream::basic_iostream(...)
std::basic_stringstream::basic_stringstream(...)
newOrder

Dynamic cast?

template<typename _CharT, typename _Traits>
void basic_ios<_CharT, _Traits>::_M_cache_locale(
    const locale& __loc) {
  if (has_facet<__ctype_type>(__loc))
    _M_ctype = &use_facet<__ctype_type>(__loc);
  else _M_ctype = 0;

  if (has_facet<__num_put_type>(__loc))
    _M_num_put = &use_facet<__num_put_type>(__loc);
  else _M_num_put = 0;

  if (has_facet<__num_get_type>(__loc)
    _M_num_get = &use_facet<__num_get_type>(__loc);
  else _M_num_get = 0;
}

Dynamic cast?

template<typename _Facet> bool
has_facet(const locale& __loc) {
  const size_t __i = _Facet::id._M_id();
  const locale::facet** __facets = __loc._M_impl->_M_facets;
  return (__i < __loc._M_impl->_M_facets_size
    && dynamic_cast<const _Facet*>(__facets[__i]));
}


Fixed in GCC 13!

dynamic_cast → static_cast short-circuit

#define _GLIBCXX_STD_FACET(...) \
  if constexpr (__is_same(const _Facet, const __VA_ARGS__)) \
    return static_cast<const _Facet*>(__facets[__i])


Profile - today (GCC 16)

11.97%  __ostream_insert
 8.75%  basic_streambuf::xsputn
 7.27%  newOrder
 6.72%  ostream::_M_insert<long>
 5.86%  num_put::_M_insert_int
 4.92%  basic_ios::_M_cache_locale
 4.43%  basic_stringbuf::overflow
 3.89%  __int_to_char

~1040ns → ~640ns  (~1.6× faster)

Lesson

• Use the newest compiler you can
• (GCC 16 for the rest of this talk)

Take Two

/// hide
#include <cstdio>
/// unhide
void newOrder(char *buf, const char *stock,
              int price, int quantity) {
  sprintf(buf, "NEW %s %d %d", stock, price, quantity);
}

Take Two - Results

• ~260ns per order
• ~4× faster
• We can still do better!

47.38%  vfprintf
21.51%  _IO_default_xsputn
 9.81%  __strchrnul
 6.80%  _itoa_word

Take Three - Rethink

• Don't need full generality of printf
• Create a custom formatter
• Maybe end up with a faster _itoa_word

How to do itoa?

• Rightmost digit is value % 10
• Next digit is (value / 10) % 10
• And so on...
• Digits come out in reverse order

Take Three

class Format {
  char _buffer[2048];
  int _ptr{0};
public:
  void append(char c) { _buffer[_ptr++] = c; }
  void append(const char *data) {
    while (*data) append(*data++);
  }
  void finish() { append('\x00'); }
  void decimalAppend(int value);
  void decimalAppendNonNeg(unsigned value);
};

Take Three

void Format::decimalAppend(int value) {
  if (value < 0) {
    append('-');
    value = -value;
  }
  decimalAppendNonNeg(value);
}

Take Three

void Format::decimalAppendNonNeg(unsigned value) {
  int startPos = _ptr;
  do {
    append(value % 10 + '0');
    value /= 10;
  } while (value);
  // Reverse the digits.
  auto end = &_buffer[_ptr - 1];
  auto start = &_buffer[startPos];
  while (end > start)
    std::swap(*start++, *end--);
}

Take Three

append(value % 10 + '0');
value /= 10;

mov r10d, 0xcccccccd
mov eax, esi          ; esi is value, move to eax
mul r10d              ; tmp = value * 0xcccccccd
                      ; eax = bot32(tmp)
                      ; edx = top32(tmp)
shr edx, 3            ; edx = value * 0xcccccccd / 2^35
                      ; 0xcccccccd / 2^35 = 0.10000000000582077
                      ; edx = floor(value / 10)

lea eax, [rdx+rdx*4]  ; eax = edx * 5
add eax, eax          ; eax *= 2, eax is now edx*10
sub esi, eax          ; esi = value - floor(value / 10) * 10
                      ; esi = value % 10
add esi, 48           ; add '0' to get ASCII
mov [rdi+rcx], sil    ; write out

Take Three

/// hide
#include <utility>
class Format {
  char _buffer[2048];
  int _ptr{0};
public:
  void append(char c) { _buffer[_ptr++] = c; }
  void append(const char *data) { while (*data) append(*data++); }
  void finish() { append('\x00'); }
  void decimalAppend(int value) {
    if (value < 0) { append('-'); value = -value; }
    decimalAppendNonNeg(value);
  }
  void decimalAppendNonNeg(unsigned value) {
    int startPos = _ptr;
    do { append(value % 10 + '0'); value /= 10; } while (value);
    auto end = &_buffer[_ptr - 1];
    auto start = &_buffer[startPos];
    while (end > start) std::swap(*start++, *end--);
  }
};
/// unhide
void newOrder(Format &format, const char *stock,
              int price, int quantity) {
  format.append("NEW ");
  format.append(stock);
  format.append(' ');
  format.decimalAppend(price);
  format.append(' ');
  format.decimalAppendNonNeg(quantity);
  format.finish();
}

Take Three - Results

• ~80ns / order
• ~13× faster than Take One
• ~3.3× faster than Take Two

Take Three - Profile

94.93% newOrder(Format&, char const*, int, int)
 4.86% main

Take Three - Profile

0.68% mov    %esi,%edx
1.66% mov    %ecx,%eax
2.09% movslq %edx,%r8
1.99% lea    0x1(%rdx),%esi
0.68% mul    %r10d
5.51% shr    $0x3,%edx
0.83% lea    (%rdx,%rdx,4),%r9d
1.65% add    %r9d,%r9d
2.06% sub    %r9d,%ecx
2.20% add    $0x30,%ecx
1.55% test   %edx,%edx
1.31% mov    %cl,(%rdi,%r8,1)
2.29% mov    %edx,%ecx

Take Three - continued

• Can we do better?
• Absolutely...

Best (so far)

• Do two digits at a time table[x % 100]; x/= 100;
• Number of digits in result, N is 1 + log₁₀(x):


            log₂(x) ~= 31 - clz(x)
            log₁₀(x) = log₂(x) * (ln(2)/ln(10))
            ln(2)/ln(10) ~= 0.30103 ~= 1233/4096


• Generate bespoke routine for N digits
• ~76ns / order (a few % over Take Three)

static unsigned const PowersOf10[] =
  {1, 10, 100, 1000, 10000, 100000,
    1000000, 10000000, 100000000, 1000000000};

static unsigned numDigits(unsigned v) {
  auto log2 = 31 - __builtin_clz(v);
  auto log10Approx = (log2 + 1) * 1233 >> 12;
  auto log10 = log10Approx - (v < PowersOf10[log10Approx]);
  return log10 + 1;
}

What about std::format?

• C++20, type-safe, no printf format-string footguns
• What you'd write today instead of stringstream

/// hide
#include <format>
#include <string>
#include <string_view>
/// unhide
std::string newOrder(std::string_view stock,
                     int price, int quantity) {
  return std::format("NEW {} {} {}",
                     stock, price, quantity);
}

std::format_to - in-place

If you already own the buffer (à la Take Two):

/// hide
#include <format>
/// unhide
void newOrder(char *buf, const char *stock,
              int price, int quantity) {
  std::format_to(buf, "NEW {} {} {}",
                 stock, price, quantity);
}

fmt::format_to - upstream

fmtlib/fmt is the upstream of std::format:

#include <fmt/core.h>

void newOrder(char *buf, const char *stock,
              int price, int quantity) {
  fmt::format_to(buf, "NEW {} {} {}",
                 stock, price, quantity);
}

Is it free?

• std::format ≈ sprintf - type-safe, not faster
• fmt::format_to ~25% faster than sprintf - same API, different implementation
• For the last 2.5×, the custom Format still wins
